Wire Displacement Sensor

Wire Displacement Sensor
Price : 12,970.00 - 45,680.00 / Piece
Get Best Price

MOQ : 1 Piece

Business Type Exporter, Supplier, Importer
Working range 500mm,600mm,700mm,800,900,1000,1100,1200
Linear precision ±0.15%FS
Repeatability accuracy ±0.02%FS
Click to view more

Preferred Buyer From

Location Worldwide

Product Details

Resistance (±10%)
5KΩ; 10 KΩ
Resolution
Infinite
Max working voltage
24V DC
Output signal
Resistance output; voltage output(0-5V, 0-10v); 4-20Ma; RS485 digital signal
Sensor type
Encoder
Max working speed
1m/s
Usage temperature
-55℃~~ +125℃
Usage life
5 million times
Traction
250±25g
Wire diameter
08mm
IP grade
IP65
Maximum quality
450g

Wire Displacement Sensor

BRG-A pull rope displacement sensor, range 500mm, .,1200mm, military grade, Sensor output signal types are: resistance output, voltage output (0-SV; 0-10V), current output (4- 20mA, two-wire or three-wire) .

BRG-A Wire Displacement Sensor

BRG-A  pull rope displacement sensor, range 500mm, .,1200mm, military grade,

Sensor output signal types are: resistance output, voltage output (0-SV; 0-10V), current output (4- 20mA, two-wire or three-wire) .



Features :

  • Small in size
  • High precision
  • Easy to install and use
  • Dedicated to machine tools, and can also be used for other special occasions.



Application

BRG-A Wire Displacement Sensor is used for storage location positioning, gate opening control, pressure machinery, papermaking machinery, textile machinery, packaging machinery, printing machinery, construction machinery, woodworking machinery, hydraulic presses and other mechanical equipment Displacement measurement and location positioning.
