Pneumatic Cylinder Linear Position Sensor

Pneumatic Cylinder Linear Position Sensor
Price : 12,970.00 - 45,680.00 / Piece
Get Best Price

MOQ : 1 Piece

Business Type Exporter, Supplier, Importer
Measuring range 50~5000mm
Performance Non-linearity < ±0.01%F.S. (minimum ±50μm), repeatability < ±0.001%F.S. (minimum ±1μm)
Operating Voltage 24VDC (-15/+20%) overvoltage protection, reverse polarity protection
Click to view more

Preferred Buyer From

Location Worldwide

Product Details

Working current
<60mA (varies with the range)
Installation method
Cylinder built-in installation, M18*1.5, M20*1.5, 3/4-16UNF or customized
Protection class
IP67 or IP68
Operating temperature
- 40℃~+85℃
Stem material
Stainless steel 304, 316
Measuring rod pressure
35MPa continuous/70MPa peak

Pneumatic Cylinder Linear Position Sensor





*Robust and reliable, oil and dirt resistant *Non-contact measurement, never wear *Absolute output, no need to return to zero *Easy to diagnose, LED lights show real-time status Modular design, easy to replace *Low-power design, effectively reducing system temperature drift





Installation


The pressure measuring rod of RH series products can be easily separated from the entire electronic compartment of the sensor (two M4X65 screws), which can be quickly replaced without pressure relief, and the pressure measuring rod can become a permanent part of the oil cylinder.





 Application





·Plastics machinery


·Fluid Power & Linear Actuators


·Hydraulics and Pneumatics


·Processing machines
